1500 Kg
EPL1531
Electric Pallet Truck 1.5T
Contact Us
About the EPL1531
The EPL153 combines EP’s smart lithium technology with a newly designed handle head for comfortable and reliable operation. With a 1.5-ton capacity, integrated charger, and compact design, it ensures efficient pallet handling in warehouses, retail stores, and distribution centers. Backed by 10-year market-tested components, the EPL153 is a durable and trusted choice.
Get a QuoteDatasheet
Product Application
Ideal for light-to-medium duty applications, the EPL153 is designed for goods movement in warehouses, shops, and logistics facilities. Its compact size and polyurethane wheels allow smooth maneuvering in narrow aisles, while the lithium battery and built-in charger support quick and convenient opportunity charging. With optional castor wheels for enhanced stability, the EPL153 adapts easily to different working environments.
Features
Smart lithium battery
The EPL153 uses Li-ion batteries with an integrated charger, ensuring fast opportunity charging without the need for a special charging area. This technology reduces downtime and makes the truck more convenient for everyday use.
Ergonomic handle head
The newly designed handle provides precise control and comfort. Lifting is electric while lowering is manual, preventing damage to goods by uncontrolled lowering and enhancing safety for operators.
Proven market reliability
With components tested and validated in the market for over 10 years, the EPL153 delivers consistent reliability, ensuring long-term performance and peace of mind for businesses.
Optional castor wheels
For added stability, especially when handling heavy or unbalanced loads, the EPL153 can be equipped with optional castor wheels, offering better balance and safety during operation.
Request a quote
Specifications for the EPL1531
| Name | Value |
|---|---|
| Manufacturer | EP |
| Model designation | EPL1531 |
| Drive | Electric |
| Operator type | Pedestrian |
| Rated capacity | 1500 kg |
| Load centre distance | 600 mm |
| Load distance, centre of drive axle to fork | 950 (880) mm |
| Wheelbase | 1190 (1120) mm |
| Service weight | 120 kg |
| Axle loading, laden front/rear | 480/1140 kg |
| Axle loading, unladen front/rear | 90/30 kg |
| Tyres | Polyurethane |
| Tyre size, front | 210x70mm |
| Tyre size, rear | Ф80x60(Ф74x88)mm |
| Wheels, number front/rear (x=drive wheels) | 1x/4(1x/2) |
| Tread width, rear | 410 (535) mm |
| Lift | ["115"] mm |
| Height drawbar in driving position min./max. | 750/1190 mm |
| Height, lowered | 82 mm |
| Overall length | 1540 mm |
| Length to face of forks | 400 mm |
| Overall width | 560 (685) mm |
| Fork dimensions | 55x150x1150 mm |
| Distance between fork-arms | 560 (685) mm |
| Ground clearance, centre of wheelbase | 30 mm |
| Aisle width for pallets 1000×1200 crossways | 2145 mm |
| Aisle width for pallets 800 × 1200 lengthways | 2050 mm |
| Turning radius | 1330 mm |
| Travel speed, laden/unladen | 4.0/4.5 km/h |
| Lift speed, laden/unladen | 0.017/0.020 m/s |
| Lowering speed, laden/unladen | 0.052/0.016 m/s |
| Max. gradeability, laden/unladen | 6/16 % |
| Service brake | Electromagnetic |
| Drive motor rating S2 60 min | 0.75 kW |
| Lift motor rating at S3 15% | 0.7 kW |
| Battery voltage | 24 V |
| Battery nominal capacity K5 | 20 Ah |
| Battery type | Li-Ion |
| Battery weight | 7 kg |
| Type of drive unit | DC |
| Steering design | Mechanical |
| Sound pressure level at the driver's seat | <74 dB(A) |
| Charger output current | 10 A |
FAQs
What type of battery does the EPL153 use?
The EPL153 is powered by a 24V/20Ah Li-ion battery with a built-in charger, allowing quick opportunity charging without the need for a special charging room.
What is the maximum load capacity of the EPL153?
The EPL153 can handle loads of up to 1.5 tons, making it suitable for everyday warehouse and retail operations.
How does the new handle design improve operation?
The redesigned ergonomic handle allows for comfortable steering and precise control. Lifting is electric while lowering is manual, preventing goods from dropping too quickly and improving safety.
Is the EPL153 easy to maintain?
Yes. With proven components tested for more than 10 years in the market, the EPL153 ensures long-term durability and requires minimal maintenance.
Can the EPL153 be customized for different applications?
Yes. The EPL153 offers optional castor wheels for additional stability and multiple fork dimension choices to adapt to various pallet standards.
