3000 kg
EFXZ301-E
4-wheel Li-ion Counterbalance Forklift 3.0T
Contact Us
About the EFXZ301-E
The EFXZ Series is the result of EP Equipment’s pioneering remanufacturing program, transforming used IC forklifts into powerful and eco-friendly Li-ion electric trucks. Designed for operators seeking both performance and value, the EFXZ series delivers load capacities of 2.5 and 3.0 tons, backed by PMSM drive motors, hydraulic steering, and zero-emission operation. Each truck undergoes a rigorous disassembly and rebuilding process, ensuring the reliability, quality, and safety of a brand-new machine at a significantly reduced total cost of ownership.
Get a QuoteDatasheet
Product Application
The EFXZ Series is ideal for warehousing, logistics centers, and manufacturing sites that demand both performance and sustainability. Its pneumatic tires and robust steel chassis provide exceptional stability for indoor and outdoor operations. The remanufactured IC base ensures strength, while the Li-ion power system offers long runtime, fast charging, and reduced maintenance. Available with multiple mast configurations and customizable fork dimensions, the EFXZ series adapts easily to diverse material handling tasks, from pallet transport to high stacking in industrial environments.
Features
Comprehensive remanufacturing process
Each EFXZ truck is completely disassembled, inspected, and rebuilt in EP’s remanufacturing facility. Critical components such as the chassis, front axle, and counterweight are refurbished, while the powertrain is replaced with a state-of-the-art lithium-ion system. This ensures the forklift delivers like-new reliability with a fraction of the cost and environmental impact.
Advanced Li-ion technology for maximum efficiency
The EFXZ is powered by EP’s 80V Li-ion battery, available in 150Ah to 410Ah configurations. The lithium system offers fast and opportunity charging, zero maintenance, and consistent power output. Combined with PMSM motors, it provides smoother acceleration, reduced noise, and higher energy efficiency compared to IC models.
Rugged performance with renewed reliability
With load capacities up to 3 tons, travel speeds of 12 km/h, and gradeability up to 20%, the EFXZ performs effortlessly across demanding applications. Its pneumatic tires, reinforced frame, and hydraulic braking system ensure dependable operation on uneven floors and outdoor terrains, meeting the same performance and safety standards as new forklifts.
Sustainable and cost-effective material handling
By reusing IC forklift structures and converting them to electric power, the EFXZ Series reduces manufacturing waste and CO₂ emissions. It offers up to 40% lower operational costs, extended service life, and full EP warranty coverage, making it a responsible and economical alternative for fleet upgrades.
Request a quote
Specifications for the EFXZ301-E
| Name | Value |
|---|---|
| Manufacturer | EP |
| Model designation | EFXZ301-E |
| Drive | Electric |
| Operator type | Seated |
| Rated capacity | 3000 kg |
| Load centre distance | 500 mm |
| Load distance, centre of drive axle to fork | 481 mm |
| Wheelbase | 1750 mm |
| Service weight | 4200 kg |
| Axle loading, laden front/rear | 6374/868 kg |
| Axle loading, unladen front/rear | 1642/2530 kg |
| Tyres | Pneumatic |
| Tyre size, front | 28X9-15-14PRmm |
| Tyre size, rear | 6.50-10-10PRmm |
| Wheels, number front/rear (x=drive wheels) | 2x/2 |
| Tread width, front | 1000 mm |
| Tread width, rear | 980 mm |
| Max lift height | 6000 mm |
| Tilt of mast/fork carriage forward/backward | 6/12 ° |
| Height, mast lowered | 2100 mm |
| Free lift | 110 mm |
| Lift | 3000 mm |
| Height, mast extended | 4110 mm |
| Height of overhead guard (cabin) | 2170 mm |
| Seat height relating to SIP/stand height | 1115 mm |
| Coupling height | 340 mm |
| Overall length | 3730 mm |
| Length to face of forks | 2690 mm |
| Overall width | 1225 mm |
| Fork dimensions | 45×122×1070 mm |
| Fork carriage ISO 2328, class/type A, B | 3A |
| Fork carriage width | 1230 mm |
| Ground clearance, laden, below mast | 150 mm |
| Ground clearance, centre of wheelbase | 200 mm |
| Aisle width for pallets 1000×1200 crossways | 4170 mm |
| Aisle width for pallets 800 × 1200 lengthways | 4098 mm |
| Turning radius | 2400 mm |
| Travel speed, laden/unladen | 11/12 km/h |
| Lift speed, laden/unladen | 0.26/0.36 m/s |
| Lowering speed, laden/unladen | 0.4/0.43 m/s |
| Max. gradeability, laden/unladen | 15/24 % |
| Service brake | Hydraulic |
| Parking brake | Mechanical |
| Drive motor rating S2 60 min | 10 kW |
| Lift motor rating at S3 15% | 16 kW |
| Battery voltage | 80 V |
| Battery nominal capacity K5 | 280 Ah |
| Battery type | Li-Ion |
| Type of drive unit | AC |
| Steering design | Hydraulic |
| Sound pressure level at the driver's seat | ﹤74 dB(A) |
FAQs
What is the EFXZ Series and how is it different from a standard electric forklift?
The EFXZ Series is EP’s innovative remanufactured Li-ion forklift line, built by converting used IC forklifts into fully electric trucks. Each unit undergoes a complete factory-level refurbishment, replacing the engine, gearbox, and fuel system with an 80V Li-ion powertrain. The result is a forklift that performs like new — but with lower emissions, reduced costs, and a smaller environmental footprint.
How reliable is a remanufactured EFXZ forklift compared to a new model?
Every EFXZ forklift is disassembled, inspected, and rebuilt according to EP’s strict manufacturing standards. Structural components are restored, and key systems such as axles, brakes, and hydraulics are replaced or reconditioned. The Li-ion battery and PMSM motors are brand-new, ensuring performance, safety, and durability equivalent to a new electric forklift — all backed by EP’s warranty.
What type of battery and power system does the EFXZ use?
The EFXZ Series features EP’s 80V Li-ion battery system, available in 150Ah to 410Ah configurations. The Li-ion technology offers fast and opportunity charging, zero maintenance, and consistent energy output. Combined with high-efficiency PMSM motors, it delivers smooth acceleration, powerful lifting, and reduced energy consumption compared to IC or lead-acid models.
In which applications does the EFXZ Series perform best?
The EFXZ Series is perfect for logistics hubs, warehouses, and manufacturing plants seeking to transition from internal combustion to electric operations. Thanks to its pneumatic tires, robust frame, and 12 km/h travel speed, it operates efficiently both indoors and outdoors, handling tasks such as pallet transport, stacking, and loading on uneven surfaces.
What are the main sustainability and cost benefits of choosing the EFXZ Series?
The EFXZ contributes to sustainable material handling by reusing IC forklift structures and significantly reducing manufacturing waste. It cuts CO₂ emissions, lowers total operating costs by up to 40%, and extends equipment lifespan. By combining circular economy principles with advanced Li-ion technology, the EFXZ offers an eco-friendly and cost-efficient alternative to new production models.
