2000 kg
WPL202
Heavy-Duty Li-ion Pallet Truck 2.0T
Contact Us
About the WPL202
With a load capacity of 2000 kg and a chassis length of just 470 mm, the WPL202 combines strength and compactness. Its 24V/100Ah Li-ion battery with integrated 30A charger ensures fast, flexible charging, while the unique synchronous castor wheels deliver excellent stability and gradeability on uneven surfaces.
Get a QuoteDatasheet
Product Application
The WPL202 is ideal for warehouses, distribution hubs, and retail environments where space utilization is critical. Thanks to its compact design and small turning radius (1320 mm), it easily navigates lorries and narrow aisles. The cold storage version (0 ~ -20°C) with waterproof components, heated battery, rubber wheels, and low-temperature hydraulic oil makes it suitable for frozen food and pharmaceutical logistics.
Features
Ultra-slim design for confined spaces
With only 470 mm chassis length and a turning radius of 1320 mm, the WPL202 is built to maximize maneuverability in tight environments such as lorries, narrow aisles, and compact warehouses. This compact size also optimizes transport and reduces freight costs.
Lithium technology with integrated charger
Equipped with a 24V/100Ah Li-ion battery and 30A integrated charger, the WPL202 supports fast opportunity charging with zero maintenance. This provides maximum uptime in multi-shift operations and greater operational flexibility.
Unique synchronous castor wheels
The WPL202 adopts synchronized castor wheels that ensure superior stability and gradeability, even when operating on ramps or uneven floors. This advanced design minimizes tipping risks and provides smoother load handling.
Cold storage option available
The WPL202 cold storage version is equipped with waterproof tiller head, heated Li-ion battery, rubber drive wheel, and low-temperature hydraulic oil, enabling reliable operation in frozen conditions down to -20°C.
Durability and user convenience
Built with market-proven components, the WPL202 guarantees long-term reliability. Options like keypad entry and telematics further enhance convenience and allow integration with modern fleet management systems.
Request a quote
Specifications for the WPL202
| Name | Value |
|---|---|
| Manufacturer | EP |
| Model designation | WPL202 |
| Drive | Electric |
| Operator type | Pedestrian |
| Rated capacity | 2000 kg |
| Load centre distance | 600 mm |
| Load distance, centre of drive axle to fork | 982 mm |
| Wheelbase | 1300 mm |
| Service weight | 320 kg |
| Axle loading, laden front/rear | 825/1495 kg |
| Axle loading, unladen front/rear | 255/65 kg |
| Tyres | Polyurethane |
| Tyre size, front | 230x75mm |
| Tyre size, rear | Ф80x115/Ф85x70mm |
| Additional wheels (castor wheels) | Ф74x30mm |
| Wheels, number front/rear (x=drive wheels) | 1 x +2 / 4 |
| Tread width, front | 483 mm |
| Tread width, rear | 370 mm |
| Max lift height | 125 mm |
| Lift | ["125"] mm |
| Height drawbar in driving position min./max. | 900/1230 mm |
| Height, lowered | 85 mm |
| Overall length | 1620 mm |
| Length to face of forks | 470 mm |
| Overall width | 714 mm |
| Fork dimensions | 55/170/1150 mm |
| Distance between fork-arms | 540/685 mm |
| Ground clearance, centre of wheelbase | 27 mm |
| Aisle width for pallets 1000×1200 crossways | 2153 mm |
| Aisle width for pallets 800 × 1200 lengthways | 2080 mm |
| Turning radius | 1320 mm |
| Travel speed, laden/unladen | 5.5/6 km/h |
| Lift speed, laden/unladen | 0.022 m/s |
| Lowering speed, laden/unladen | 0.039 m/s |
| Max. gradeability, laden/unladen | 10/16 % |
| Service brake | Electromagnetic |
| Drive motor rating S2 60 min | 1.6 kW |
| Lift motor rating at S3 15% | 0.8 kW |
| Battery voltage | 24 V |
| Battery nominal capacity K5 | 100 Ah |
| Battery type | Li-Ion |
| Battery weight | 44 kg |
| Energy consumption according to DIN EN 16796 | 0.256kWh/h |
| Turnover output according to VDI 2198 | 85.16 |
| Turnover efficiency according to VDI 2198 | 171.35 |
| Type of drive unit | AC |
| Steering design | Mechanical |
| Sound pressure level at the driver's seat | 70 dB(A) |
FAQs
What is the maximum load capacity of the WPL202?
The WPL202 can handle up to 2.0 tons, making it a reliable solution for heavy-duty warehouse and distribution tasks.
What type of battery does the WPL202 use?
It is powered by a 24V/100Ah Li-ion battery with an integrated 30A charger. This design supports fast opportunity charging and reduces downtime during multi-shift operations.
How does the WPL202 ensure stability during operation?
The truck features unique synchronous castor wheels that improve stability and gradeability, even when operating on ramps or uneven floors.
Is there a cold storage version of the WPL202?
Yes. The cold storage configuration includes a heated Li-ion battery, waterproof tiller head, rubber drive wheel, and low-temperature hydraulic oil, making it suitable for environments down to -20°C.
Are there customization options available for the WPL202?
Yes. Options include keypad access, telematics integration for fleet management, and various fork sizes to adapt the truck to different applications.
