1800 kg
EPL185
Electric Pallet Truck 1.8T
Contact Us
About the EPL185
The EPL185 combines stability, strength, and compactness in one design. With a load capacity of 1.8 tons, floating stabilizing wheels, and a 48V/20Ah removable Li-ion battery, it ensures safe and agile operation. Its integrated charger and optional fast charging provide maximum flexibility, while the plug-in/out battery design with protective metal cover improves safety and reliability.
Get a QuoteDatasheet
Product Application
Ideal for warehouses, retail, and logistics environments, the EPL185 is designed for operations requiring both high load capacity and maneuverability. Its compact chassis (400 mm fork face length) makes it suitable for confined spaces, while the stabilizing wheels ensure balance even on uneven surfaces. Thanks to optional fork dimensions, larger battery capacities, and additional attachments, it adapts to diverse customer requirements.
Features
Stable and safe handling
Industrial floating stabilizing wheels come as standard, providing excellent stability and smooth load transport, even on slightly uneven floors.
Advanced battery system
Equipped with a 48V/20Ah removable Li-ion battery with BMS and CAN technology, the EPL185 offers safety, reliability, and the flexibility of optional 30Ah capacity.
Brushless drive technology
The brushless DC motor eliminates the need for carbon brush replacement, improving efficiency and reducing maintenance while ensuring stronger driving power.
Compact & maneuverable
With only 400 mm fork face length and 170 kg service weight, the EPL185 is compact enough for tight aisles but strong enough to handle loads up to 1.8 tons.
Request a quote
Specifications for the EPL185
| Name | Value |
|---|---|
| Manufacturer | EP |
| Model designation | EPL185 |
| Drive | Electric |
| Operator type | Pedestrian |
| Rated capacity | 1800 kg |
| Load centre distance | 600 mm |
| Load distance, centre of drive axle to fork | 940 mm |
| Wheelbase | 1200 mm |
| Service weight | 170 kg |
| Axle loading, laden front/rear | 640/1330 kg |
| Axle loading, unladen front/rear | 130/40 kg |
| Tyres | Polyurethane |
| Tyre size, front | 210x70mm |
| Tyre size, rear | 80x61/88x78mm |
| Wheels, number front/rear (x=drive wheels) | 1x 2/4(1x 2/2) |
| Tread width, front | 450 mm |
| Tread width, rear | 390/(535) mm |
| Max lift height | 115 mm |
| Lift | ["115"] mm |
| Overall length | 1550 mm |
| Length to face of forks | 400 mm |
| Overall width | 610 (695) mm |
| Fork dimensions | 50x150x1150 mm |
| Aisle width for pallets 1000×1200 crossways | 2094 mm |
| Aisle width for pallets 800 × 1200 lengthways | 2146 mm |
| Turning radius | 1330 mm |
| Travel speed, laden/unladen | 5/5.5 km/h |
| Lift speed, laden/unladen | 0.020/0.025 m/s |
| Lowering speed, laden/unladen | 0.065/0.030 m/s |
| Max. gradeability, laden/unladen | 6/16 % |
| Service brake | Electromagnetic |
| Drive motor rating S2 60 min | 0.9 kW |
| Lift motor rating at S3 15% | 0.8 kW |
| Battery voltage | 48 V |
| Battery nominal capacity K5 | 20 Ah |
| Battery type | Li-Ion |
| Battery weight | 14 kg |
| Type of drive unit | DC |
| Steering design | Mechanical |
| Sound pressure level at the driver's seat | 74 dB(A) |
FAQs
What is the maximum load capacity of the EPL185?
The EPL185 can handle up to 1.8 tons, offering higher performance than standard 1.5-ton pallet trucks.
What makes the EPL185 more stable than other models?
It comes equipped with industrial floating stabilizing wheels as standard, which improve balance and ensure smooth operation even on slightly uneven floors.
What type of battery powers the EPL185?
The truck is powered by a removable 48V/20Ah Li-ion battery with BMS and CAN communication. An optional 30Ah battery is available for longer runtime.
How does the EPL185 reduce maintenance costs?
Its brushless DC drive motor eliminates the need for carbon brush replacement, improving durability and lowering long-term service costs.
Is the EPL185 suitable for confined spaces?
Yes. With a compact 400 mm fork face length and a service weight of only 170 kg, the EPL185 is easy to maneuver in narrow aisles and tight warehouse environments.
